Burners & BTUs

Choosing Burner Output

Burner selection is based on the available BTU capacity of your gas line. If a gas line is already installed, the burner must not exceed what it can safely supply, which determines whether a standard or max output option is appropriate.

If a gas line has not yet been installed, you may choose your preferred burner output and coordinate sizing with a licensed gas professional. If output needs to be adjusted due to site limits or design goals, we can recommend a properly matched burner or an alternative lower output option such as stainless steel.

SQUARE, ROUND, and OCTAGONAL FIRE FEATURES

Brass Jet Pro Series – Standard Output
(Dimension shown is overall diameter or side length)

36" diameter or square | 19" opening | 11" burner | 110k NG | 90k LP
48" diameter or square | 25" opening | 14" burner | 125k NG | 105k LP
60" diameter or square | 31" opening | 18" burner | 145k NG | 124k LP
72" diameter or square | 37" opening | 25" burner | 260k NG | 240k LP

SQUARE, ROUND, and OCTAGONAL FIRE FEATURES

Brass Jet Pro Series – Max Output
(Dimension shown is overall diameter or side length)

36" diameter or square | 19" opening | 14" burner | 125k NG | 105k LP
48" diameter or square | 25" opening | 18" burner | 145k NG | 124k LP
60" diameter or square | 31" opening | 25" burner | 260k NG | 240k LP
72" diameter or square | 37" opening | 32" burner | 426k NG | 402k LP

LINEAR FIRE FEATURES

Brass Jet Pro Series – Standard Output
(Dimension shown is overall length)

48" length | 30" × 10" opening | 24" linear jet burner | 50k NG | 60k LP
60" length | 36" × 10" opening | 34" linear jet burner | 90k NG | 95k LP
72" length | 48" × 10" opening | 42" linear jet burner | 100k NG | 110k LP
84" length | 60" × 10" opening | 56" linear jet burner | 135k NG | 140k LP
94" length | 72" × 10" opening | 68" linear jet burner | 140k NG | 170k LP

LINEAR FIRE FEATURES

Brass Jet Pro Series – Max Output
(Dimension shown is overall length)

48" length | 30" × 10" opening | 24" H style jet burner | 80k NG | 110k LP
60" length | 36" × 10" opening | 30" H style jet burner | 95k NG | 115k LP
72" length | 48" × 10" opening | 40" H style jet burner | 120k NG | 150k LP
84" length | 60" × 10" opening | 50" H style jet burner | 160k NG | 175k LP
94" length | 72" × 10" opening | 60" H style jet burner | 180k NG | 200k LP
119" length | 96" × 10" opening | 80" H style jet burner | 250k NG | 240k LP

Ignition Options

Match Lit (Standard)

• Light manually with a lighter or match
• Manual key valve for flame adjustment

Push Button Spark Ignition

• Push button spark start, battery powered
• Manual key valve for flame adjustment

Push Button with Flame Sensing

• Push button start with built in flame detection
• Automatically shuts off gas if the flame goes out
• Manual key valve for flame adjustment

Electronic Switch Ignition (Flame tec WeatherSmart™)

• Hardwired electronic ignition with automatic relight and flame sensing
• Includes 12V AC transformer for standard 110 or 120V connection
• Operates by wall switch or building control system
• Manual key valve for flame adjustment
• Must be installed at least 10 feet from any pool, spa, or body of water

 Optional Electronic Add Ons:

 • Bluetooth or WiFi Module – allows remote On Off control through your phone

 • WeatherSmart Power Supply – waterproof low voltage power unit for outdoor use

Powder Coat Finish Types

We use premium Prismatic Powders finishes selected for durability, visual depth, and long term outdoor performance.

Texture
Matte finish with a lightly raised surface
Excellent at hiding wear, fingerprints, and minor imperfections
Adds depth and reduces glare in bright outdoor environments

Solid
Smooth, uniform color with a clean, modern appearance
Best for minimalist and architectural designs
Provides consistent coverage and crisp edges

Metallic
Fine metallic flake for a subtle sheen or soft sparkle
Adds dimension without appearing glossy
Ideal for elevated residential and hospitality settings

Leatherette Texture
Textured finish that mimics the grain of leather
Creates a rich, tactile appearance with visual warmth
Often used where a softer, more refined surface is desired

Vein Texture
Textured two tone or marbled effect
Offers bold contrast and visual character
Naturally disguises dust, wear, and outdoor exposure over time

These powder coat finishes are chosen not only for aesthetics but also for UV stability, corrosion resistance, and long term color retention, making them well suited for exterior fire features and architectural applications.

You may purchase physical powder coat samples directly on our site for all standard colors. This allows you to review color and texture before finalizing your selection.

You may also explore the full color libraries from our preferred suppliers:

• Prismatic Powders

• Columbia Coatings

Not all available colors are stocked as standard options. Contact us to confirm availability and suitability.

What’s Included

Each fire pit, fire table, sculpture, or fire feature includes everything required for operation, except for the final gas and electrical connections.

• High quality aluminum alloy or metal fire pit, table, or feature vessel
• High efficiency burner and all required burner components
• Match lit ignition system standard unless an upgraded ignition is selected
• 3/4 inch key valve for fuel and flame adjustment
• Whistle free flex gas lines and all required fittings
• Aluminum burner pan or plate depending on product design
• Optional accessories, if purchased, may include fire media, wind guards, covers, lids, lighting, or other items listed on the order confirmation.

The Vessel comes fully assembled and Burner and electronic components are shipped uninstalled to prevent damage during transport. All vessels are pre-fitted and pre-drilled for proper component placement, and burner assemblies are pre-mounted to the pan when practical to simplify final setup.

Installation Notes

• Final gas and electrical connections must be completed by a licensed professional in your local area.
• Our systems are designed with minimal components and straightforward layouts to simplify installation while maintaining premium build quality.
• Flame sensing and electronic ignition systems are strongly recommended for fire features exceeding 200,000 BTU.

Shipping and Lead Time Policy

Shipping Policy

All products ship from our facilities or our network of domestic fabrication and fulfillment partners. Shipping methods and costs are determined by product size, weight, destination, and delivery requirements.

Smaller components and accessories typically ship via standard ground carriers. Larger fire pits, fire tables, fire and water features, and custom fabrications ship crated by freight due to size and handling requirements.

Freight deliveries are curbside only with liftgate service and require a delivery appointment scheduled by the carrier. Placement, uncrating, and installation are not included.

Shipping charges are calculated at checkout or quoted separately for larger or custom orders. Delivery methods and estimated timelines are provided prior to shipment.

Customers are responsible for ensuring adequate site access for delivery vehicles. Any special delivery requirements must be communicated prior to order placement.

All shipments should be inspected upon delivery. Any visible damage must be noted on the carrier’s paperwork before signing.

Lead Time and Delivery Expectations

Most products are made to order and fabricated specifically for each project. Lead times vary based on product type, finish selection, burner system, and current production schedules.

Estimated lead times are provided for planning purposes only and are not guaranteed ship dates. Production schedules may be affected by material availability, finishing processes, quality control, and logistics.

Transit time begins once an order leaves the fabrication facility and is dependent on carrier scheduling and destination. Modofire is not responsible for delays caused by freight carriers, weather conditions, or site access limitations.

We recommend coordinating installation and contractor schedules only after shipment confirmation has been provided.

Warranty and Product Coverage

At Modofire, all fire features—whether designed and fabricated by us or produced in collaboration with our trusted manufacturing partners—are held to the same standards of quality and performance. Warranty coverage is divided between the fire vessel or enclosure and the internal burner and control components.

Fire Vessel and Enclosure

5-Year Limited Warranty

Covers the structural integrity of Modofire-made and partner-fabricated fire vessels and enclosures, including materials and workmanship, under normal outdoor use and proper installation.

This warranty applies to aluminum, steel, and metal enclosures supplied as part of a complete Modofire fire feature.

Internal Components

Modofire integrates premium burners, ignition systems, and gas components from industry-leading manufacturers. These components are covered under their respective limited warranties as outlined below.

Component Coverage

Stainless steel and brass burners
Residential: Lifetime
Commercial: Lifetime

Electronics and gas valves
Residential: 3 years
Commercial: 1 year

Pilot assemblies
Residential: 2 years
Commercial: 1 year

Stainless steel burner pans or valve boxes
Residential: 5 years
Commercial: 1 year

Warranty Terms

Warranty coverage begins on the original shipment or purchase date.
Coverage includes replacement parts and factory repair labor only.
Installation, removal, freight, and on-site labor are not included.
Warranty claims require a valid RMA issued by Modofire or the applicable component manufacturer.

Warranty Exclusions

This warranty does not apply to damage resulting from:

Improper installation or failure to follow manufacturer guidelines
Overheating, misuse, or operation outside rated specifications
Unauthorized modifications or repairs
Use in unsuitable or extreme environments not intended for the product

The following are not covered:

Normal wear and tear
Surface finish changes, patina development, or aesthetic aging
Heat-related discoloration or weather-related finish variation
Consequential or indirect damages

Return and Cancellation Policy

At Modofire, the majority of our products are custom made to order and fabricated specifically for each project. This policy reflects the time, materials, and coordination required to produce high-quality fire features and architectural elements.

Order Cancellations

Within 72 Hours of Order Placement
Orders may be cancelled for a full refund.

After 72 Hours and Prior to Production
A cancellation fee of 3 percent applies to cover administrative and payment processing costs.

After Production or Shipment Begins
Orders may no longer be cancelled. This includes all custom, made-to-order, and fabricated products.

Returns

Most Modofire products are not eligible for return due to their custom, made-to-order nature.

Non-returnable items include, but are not limited to:

Fire pits, fire tables, fire bowls, planters, fire and water features, and sculptures
Aluminum, steel, or concrete GFRC products
Any product marked made-to-order, custom, or one of a kind
Installed, used, modified, sale, or clearance items

Eligible Standard Items

If a product is identified as a standard, non-custom item, it may be eligible for return under the following conditions:

Item must be unused and in original packaging
Return must be requested within 30 days of delivery
A valid Return Authorization Number (RAN) is required
A 12 percent restocking fee applies
Buyer is responsible for return shipping and freight costs

Refunds are issued to the original payment method after the item is received and inspected.

Custom and Artistic Products

Due to the artisan and fabricated nature of Modofire products, minor variations in color, texture, finish, or surface appearance are expected and are not considered defects. These variations do not qualify for return or refund.

Exceptional Circumstances

In rare situations such as significant production issues, material unavailability, or force majeure events, Modofire reserves the right to cancel an order. In such cases, a full refund will be issued to the original payment method.
